Hydraulic Nursery Fork
Cat® Nursery forks for Compact Wheel loaders, Compact Track Loaders, and Skid Steer Loaders are designed to allow pivoting one fork out for gained maneuverability and handling capabilities in nursery and landscaping applications. Fork tines can be configured with a manually adjusted fork or hydraulically side shifting fork to give greater flexibility when handling multiple or different sized root balls.
Overall Length
98.1 in
Overall Width
52.2 in
Weight
798 lb
Specification
Value
Overall Length
98.1 in
Overall Width
52.2 in
Weight
798 lb
Overall Height
56.2 in
Usable Tine Length
70.4 in
Length Between Adjustments
Variable
Number of Adjustments
Variable
Total Tine Movement
393 in
Angled Tine Opening Minimum at Tip
1.9 in
Angled Tine Opening Maximum at Tip
47.1 in
Parallel Tine Opening Minimum
8.9 in
Parallel Tine Opening Maximum
24.3 in
Maximum Root Ball Diameter
54 in
Maximum Lifting Capacity
3000 lb
Optimal Hydraulic Flow
49-87 lpm (12-23 gpm)
Optimal Hydraulic Pressure
170-241 bar (2500-3500 psi)
Interface Type
Skid Steer Coupler
Required Hydraulics
Standard Flow, 14 Pin Electrical
Allows for greater control and maximizes proper fit when handling different sized root balls.
Pivoting fork allows maximum opening to grasp larger root balls.
Provides a secure grip on the load for maximum load retention. Fork angles at 25 degrees to closely match the standard angle on most root balls.
Integrated grab handle allows a secure contact point upon entry/exit of the machine for the operator.
Deeply serrated step provides secure footing for operators entering and exiting machines.
Tool mounted and sealed from the elements, this holder includes all the operation manuals and maintenance guides required for proper operation of the tool.
