Specification
Value
Overall Width
90.4 in
Sweeping Width
72 in
Brush Diameter
26 in
Required Hydraulics
Standard Flow
Height
34.3 in
Length
72.3 in
Weight
1256.6 lb
Required Hydraulic Flow
42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure
145-235 bar (2100-3400 psi)
Motor Displacement
24.7 in³/rev
Brush Speed at Maximum Flow
199 rpm
Hopper Capacity
0.6 yd³
Gutter Brush Weight
90.4 lb
Drive Method
Direct Drive
Ideal for cleaning and removing dirt, rock, snow and other debris from streets, parking lots, driveways, sidewalks and factory floors.
Large hopper capacity allows greater productivity with longer sweeping cycles. Wide bucket opening permits fast, efficient dumping.
Adjustable volumizer allows more material retention in hopper, giving operator more sweeps before stopping to empty material.
Heavy-duty low profile pneumatic guide wheel supports the hood during sweeping.
Optional all-steel wire gutter brush mounted on the left or right side of the broom assists in removing material from gutters and pavement edges.
An optional water sprinkler kit is available which helps reduce the amount of airborne dust during sweeping operations.
Standard broom material is made of replaceable polypropylene and steel wire sections. Optional replacement brushes include all polypropylene and all steel wire.
Interior deflectors, rear bucket seal, and side brush stripping direct dirt and dust into the bucket, reducing spillage and air-borne contaminants.
Dual chain and loader arm bracket system holds broom housing horizontally when emptying the hopper.
Bristle height adjustments have been simplified with the use of handle and a tool-less locking feature.
Motor serviceability is enhanced with a handle shaped motor bracket, core connection is close to broom wall and single retention pins allow for quick brush change and less downtime.
Replaceable bolt-on cutting edges increase wear life of hopper bucket.
Tool mounted and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.
