854
Engineered for demanding work in large dozing applications, the Cat® 854 Wheel Dozer is the largest in the Cat lineup and is an ideal match for large mining operations, power-generating utilities, the general contracting industry and wherever mobility, versatility and compaction are needed. Like all Cat Wheel Dozers, the 854 is designed with durability built in, ensuring maximum availability through multiple lifecycles. With optimized performance and simplified serviceability, the 854 will allow you to move more material efficiently and safely at a lower cost per ton.
Engine Model
Cat C32B
Gross Power
907 HP
Operating Weight
224,647 lb
Specification
Value
Engine Model
Cat C32B
Gross Power
907 HP
Emissions (U.S. EPA Tier 4 Final): Gross Power - SAE J1995
900 HP
Emissions (U.S. EPA Tier 4 Final): Net Power ISO - 9249
814 HP
Emissions (Tier 2 Equivalent): Gross Power - SAE J1995
907 HP
Emissions (Tier 2 Equivalent): Net Power ISO - 9249
823 HP
Rated Speed
1750 r/min
Bore
5.7 in
Stroke
6.4 in
Displacement
1958 in²
Peak Torque - 1,200 rpm
3139 lb/ft
Torque Rise
30 %
Note (1)
Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, muffler and alternator.
Note (2)
Net torque rise meets SAE J139.
Note (3)
No engine derating required up to 3050 m (10,000 ft) altitude.
Specification
Value
Operating Weight
224,647 lb
Specification
Value
Transmission Type
Cat Planetary Power Shift
Converter Drive - Forward 1
4.4 mile/h
Converter Drive - Forward 2
7.7 mile/h
Converter Drive - Forward 3
13.2 mile/h
Converter Drive - Reverse 1
4.8 mile/h
Converter Drive - Reverse 2
8.4 mile/h
Converter Drive - Reverse 3
14.6 mile/h
Direct Drive - Forward 1
Lock-up disabled
Direct Drive - Forward 2
8.1 mile/h
Direct Drive - Forward 3
14.2 mile/h
Direct Drive - Reverse 1
5 mile/h
Direct Drive - Reverse 2
8.9 mile/h
Direct Drive - Reverse 3
15.6 mile/h
Note
Travel speeds based on 45/65-45 L-5 46 ply tires.
Specification
Value
Output at 1,850 rpm and 6900 kPa (1,000 psi)
161 gal/min
Cylinders, Double Acting - Lift, Bore and Stroke
177 mm × 1760 mm (0.58 ft × 5.8 ft)
Cylinder, Double Acting - Tilt and Tip, Bore and Stroke
267 mm × 286 mm (0.88 ft × 0.94 ft)
Specification
Value
Fuel Tank - Standard
413 gal (US)
Cooling System
53 gal (US)
Crankcase
32 gal (US)
Transmission
45 gal (US)
Differential - Final Drives - Front
98 gal (US)
Differential - Final Drives - Rear
90 gal (US)
Hydraulic System - Steering and Engine Cooling Fan - Tank Only
77 gal (US)
Note (1)
- All nonroad U.S. EPA Tier 4, European Union (EU) Stage IIIB and V, and Japan (MLIT) Step 4 diesel engines are required to use only Ultra Low Sulfer Diesel (ULSD) fuels containing 15 ppm (mg/kg) sulfer or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfer or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214. Cat DEO-ULS or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. For further fluid specifications and guidelines, visit: http://parts.cat.com/cda/files/3244668/7/SEBU6250-19.pdf
Specification
Value
Front
Fixed
Rear
Trunnion
Specification
Value
Brakes
Meets ISO 3540:2011
Specification
Value
Blade Capacities
30.5 to 44.8 m3 (40 to 58.6 yd3)
Specification
Value
Height - Top of ROPS
18.25 ft
Height - Top of Exhaust Pipe
17.17 ft
Height - Top of Hood
13 ft
Ground Clearance
27 in
Centerline of Front Axle to Hitch
9.67 ft
Centerline of Rear Axle to Edge of Bumper
13.75 ft
Wheel Base
19.25 ft
Length - With Blade on Ground
44 ft
Specification
Value
Steering System - Pump
Piston, variable displacement
Minimum Turning Radius - Over Blade
31 ft
Steering System - Circuit
Pilot, load sensing
Total Steering Angle
86 degrees
Relief Valve Setting
5004 psi
Specification
Value
Operating Weight
224647 lb
Specification
Value
Sound Performance
• The machine sound power level was measured according to
ISO 6395:2008. The measurement was conducted at 70 percent
of the maximum engine cooling fan speed.
• The operator sound pressure level was measured according to
ISO 6396:2008. The measurement was conducted at 70 percent
of the maximum engine cooling fan speed.
• Hearing protection may be needed when the machine is operated
with a cab that is not properly maintained or when the doors or
windows are open for extended periods or in a noisy environment.
Specification
Value
Air Conditioning
The air conditioning system on this machine contains the fluorinated
greenhouse gas refrigerant R134a (Global Warming Potential = 1430).
The system contains 1.8 kg of refrigerant which has a CO2 equivalent
of 2.574 metric tonnes.
Specification
Value
ROPS/FOPS
ISO 3471:2008 and ISO 3449:2005 Level II Standards
