1.5 m3 (2.0 yd3), ISO Coupler, Weld-On Teeth
Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
Width
95.8 in
Weight
1490.1 lb
Height
42.2 in
Specification
Value
Width
95.8 in
Weight
1490.1 lb
Height
42.2 in
Length
45.1 in
Capacity
2 yd³
Base Edge Thickness
0.7 in
Number of Teeth
8
Interface Type
ISO Coupler
Ideal for rough grading, utilizing the rear cutting edge, loading and handling. The fill factor for Performance Series buckets can be up to 115% on top of the specified capacity.
Additional wear plates on bottom surface of bucket improves bucket life in course aggregate applications.
Performance Series Technology - Innovations in bucket design that improve load-ability of buckets, increasing productivity and decreasing fuel costs.
Bucket capacity and loading characteristics are matched to machine capabilities to ensure maximum usage and productivity.
