Specification
Value
Overall Width
78.3 in
Sweeping Width
60 in
Brush Diameter
26 in
Required Hydraulics
3rd Function
Height
34.3 in
Length
72.3 in
Weight
1159.6 lb
Required Hydraulic Flow
40-150 L/min (11-40 gpm)
Optimal Hydraulic Pressure
150-260 bar (2176-3771 psi)
Motor Displacement
24.7 in³/rev
Brush Speed at Maximum Flow
385 RPM
Hopper Capacity
0.5 yd³
Gutter Brush Weight
90.4 lb
Voltage
12V and 24V
Drive Method
Direct Drive
Interface Type
Requires Hook Group
The BP22 is powered by one hydraulic motor, the BP25 is powered by two hydraulic motors. Each motor is mounted to protect them from damage.
Parking supports provide stable and secure parking of the broom when not in use.
Pickup Brooms incorporate a unique suspension system to eliminate the need for support wheels. This allows the broom to float freely over the work surface and ensures proper bristle contact from the initial setting.
Leveling indicator allows operator to conveniently see the level of the broom from the cab during operation.
Pickup Brooms include a large hopper for greater productivity and easy removal and emptying.
The BP22 and BP25 both feature a 400 L (106 gallons) capacity integrated water tank.
Water sprinkler kit helps reduce the amount of airborne dust during sweeping operations.
Tool mounted and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.
Cat® Pickup Brooms come standard with replaceable polypropylene sections. Convoluted bristle sections can be converted to all wire or 50/50 poly and wire for special applications.
