1829 mm (72 in)
Cat® Utility Grapple Forks for Cat Skid Steer Loaders and Compact Track Loaders are designed to handle light, hard to handle materials encountered on a farm, ranch or landscaping project. The light duty design offers grasping capabilities for materials such as loose hay, straw, bedding materials, dry compacted livestock waste, landscaping mulch, pine straw and pierceable objects. NOTE: Utility grapple forks are not designed for piercing and carrying large, round bales.
Width
72 in
Height - Grapples Closed
30.3 in
Jaw Opening
34.5 in
Specification
Value
Width
72 in
Height - Grapples Closed
30.3 in
Jaw Opening
34.5 in
Length
37 in
Usable Tine Length
25.1 in
Weight
718.7 lb
Tine Diameter
1.3 in
Number of Tines
9
Tine Width
1.3 in
Interface Type
Skid Steer Coupler
Designed to handle light, hard to handle materials encountered on a farm, ranch or landscaping project.
Light-duty design offers grasping capabilities for materials such as loose hay, straw, bedding materials, dry compacted livestock waste, landscaping mulch and pine straw.
Wide vertical jaw opening allows for handling of bulky material.
Heavy Duty grapple allow for clamping and grasping of odd shaped materials. Single grapple with wide clamp will grasp non uniform materials such as logs, rocks, and hay.
NOTE: Utility Grapple Forks are not designed for piercing and carrying large, round bales.
