1524 mm (60 in)
Cat® Log & Lumber Forks are used to load, unload, move deck, sort and feed the mill. Their flat fork tines and raised guards are designed specifically for use in handling both unfinished logs and stacked lumber.
Overall Length
67 in
Length
60 in
Width
5.9 in
Specification
Value
Overall Length
67 in
Length
60 in
Width
5.9 in
Height
38 in
Tine Thickness
2.6 in
Load Capacity
7639 lb
Weight
396.8 lb
Tine Configuration
Swinging, Floating
Cat® Log & Lumber Fork Tines are used to load, unload, move deck, sort and feed the mill. Their flat fork tines and raised guards are designed specifically for use in handling both unfinished logs and stacked lumber.
Increased tine drop provides increased visibility for truck loading.
Tapered box tines are tapered to a point enabling the operator to insert the tines between logs for sorting and assist in a more controlled unloading of the payload.
Wider tine widths provide a larger surface area for stability when transporting larger materials.
