Specification
Value
Rating Prime
150 kVA
Frequency
50/60 Hz
Voltage
127 - 480 V
Specification
Value
Engine
Cat C7.1
Fuel
Diesel
Specification
Value
Width
44.1 in
Height
87.6 in
Length
138.6 in
Weight - With Lube Oil and Coolant
5615 lb
Specification
Value
100% Load 50Hz
9.9 gal/hr
100% Load 60Hz
11.2 gal/hr
75% Load 50Hz
7.8 gal/hr
75% Load 60Hz
9.2 gal/hr
50% Load 50Hz
5.4 gal/hr
50% Load 60Hz
6.3 gal/hr
Specification
Value
100% Load 50Hz
8.8 gal/hr
100% Load 60Hz
10.5 gal/hr
75% Load 50Hz
6.5 gal/hr
75% Load 60Hz
7.7 gal/hr
50% Load 50Hz
4.3 gal/hr
50% Load 60Hz
5 gal/hr
Specification
Value
Sound Power @ 1 meters (3 feet) @ 75% of rating (50Hz)
73.1 dB(A)
Sound Power @ 1 meters (3 feet) @ 75% of rating (60Hz)
76.4 dB(A)
Specification
Value
Sound Power @ 1 meters (3 feet) @ 75% of rating (50Hz)
74.7 dB(A)
Sound Power @ 1 meters (3 feet) @ 75% of rating (60Hz)
78.3 dB(A)
Robust, durable product with a range of rental ready features to meet job requirements and applications.
Emissions Equivalent to R96 EU Stage IIIA or Best Fuel Efficiency.
Industry proven reliability.
Easy to use digital controls.
Integrated voltage regular for fast response in demanding applications.
Inhibits corrosion in service. Prevents water ingress, provides security and sound attenuation.
Improved operator comfort.
Remote monitoring for fleet management and asset tracking.
Single-source Supplier
- Cat dealers have over 1,800 dealer branch stores operating in 200 countries
- Your local Cat dealer provides extensive post-sale support, including maintenance and repair agreements
Reducing operating costs and producing less waste.
Drag bars, Lifting frame, Fork lift pockets and 4 point lift.
Synchronising controls. Distribution sockets. Extended Service interval kits.
