Specification
Value
Maximum Rating
3500 kVA
Minimum Rating
3000 kVA
Emissions/Fuel Strategy
Tier 2 Equivalent - 1808 rpm
Voltage
380 to 11000 volts
Frequency
50 Hz
Speed
1808 rpm
Duty Cycle
Standby, Mission Critical
Specification
Value
Engine Model
3516E, V-16, 4-Stroke Water-Cooled Diesel
Bore
6.69 in
Stroke
8.46 in
Displacement
4765 in³
Compression Ratio
14.7:1
Aspiration
ATAAC
Fuel System
Electronic Unit Injection
Governor Type
Adem™5
Specification
Value
Length - Minimum
353.3 in
Length - Maximum
363.1 in
Width - Minimum
104 in
Width - Maximum
104 in
Height - Minimum
132.6 in
Height - Maximum
131.6 in
Dry Weight - Genset (minimum)
47,620 lb
Dry Weight - Genset (maximum)
52,911 lb
- Cat generator set packages have been fully prototype tested
- Accepts 100% block load in one step and meets NFPA 110 loading requirements
- Conform to ISO 8528-5 steady state and transient response requirements
- Reliable, rugged, durable design
- Field-proven in thousands of applications worldwide
- Four-stroke-cycle diesel engine combines consistent performance and excellent fuel economy with minimum weight
- Superior motor starting capability minimizes need for oversizing alternator
- Designed to match performance and output characteristics of Cat diesel engines
- Robust Class H insulation
- User-friendly interface and navigation
- Scalable system to meet a wide range of installation requirement
- Expansion modules and site-specific programming for specific customer requirements
- Designed to operate in standard ambient temperatures up to 50�C (122�F)
- Contact your Cat Dealer for specific ambient and altitude capabilities
- EU Declaration of Conformity
- EU Declaration of Incorporation
- Eurasian Conformity (EAC)
- Components used in the generator set are selected at the design stage to provide optimum package performance
- The generator set is fully assembled at a Caterpillar facility following our quality guidelines
- Each generator set package is tested before leaving the Caterpillar facility
- Cat product support, including dealer service, parts and warranty covers the entire Cat power system
- Cat dealers have over 1,800 dealer branch stores operating in 200 countries
- Your local Cat dealer provides extensive post-sale support, including maintenance and repair agreements
