Specification
Value
Net Power - ISO 9249
113 HP
Engine Model
C4.4
Engine Power - ISO 14396
125 HP
Bore
4.13 in
Stroke
5 in
Displacement
269 in³
Specification
Value
Main System - Maximum Flow
272 l/min (72 gal/min)
Maximum Pressure - Equipment
5080 psi
Maximum Pressure - Swing
3280 psi
Specification
Value
Swing Speed
8.9 r/min
Maximum Swing Torque
32970 ft·lbf
Specification
Value
Operating Weight
39463 lb
Specification
Value
Fuel Tank Capacity
79.3 gal (US)
Cooling System
5.2 gal (US)
Engine Oil
4.3 gal (US)
Swing Drive
0.8 gal (US)
Final Drive - Each
1.6 gal (US)
Hydraulic System - Including Tank
26 gal (US)
Hydraulic Tank
22 gal (US)
Specification
Value
Boom
Reach 5.1 m (16'9")
Stick
R2.6 m (8'6")
Bucket
GD .76 m³ (1.0 yd³)
Shipping Height - Top of Cab
9.92 ft
Shipping Length
28 ft
Tail Swing Radius
8.17 ft
Counterweight Clearance
3.25 ft
Ground Clearance
1.5 ft
Track Length
13 ft
Length to Center of Rollers
10.42 ft
Track Gauge
6.5 ft
Transport Width
8.5 ft
Specification
Value
Maximum Digging Depth
20 ft
Boom
Reach 5.1 m (16'9")
Stick
R2.6 m (8'6")
Bucket
GD .76 m³ (1.0 yd³)
Maximum Reach at Ground Level
28.8 ft
Maximum Cutting Height
29.3 ft
Maximum Loading Height
20.6 ft
Minimum Loading Height
7.6 ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom
19.3 ft
Maximum Vertical Wall Digging Depth
16.3 ft
Bucket Digging Force - ISO
25000 lbf
Stick Digging Force - ISO
17900 lbf
- A powerful C4.4 electrically controlled engine meets U.S. EPA Tier 3, EU Stage IIIA equivalent and China Nonroad Stage III emission standards.
- Two-pump hydraulic system pressure delivers terrific digging performance and productivity.
- Hydraulic cross-sensing system uses two hydraulic pumps under all operating conditions, improving productivity with faster implement speeds and quicker, stronger pivot turns.
- Economy mode maintains breakout forces and lift capacity at standard power, balancing demands of performance and fuel economy.
- Boom and stick regeneration circuits save energy during boom-down and stick-in operation.
- New compact design utilizes shorter tubes and lines to reduce friction and pressure drops, resulting in more efficient use of power.
- The service door on the right side of the upper structure allows ground-level access to the pump, pilot filter, drain filter, and the engine oil filter.
- Easily accessible, ground-level service locations allow quick and efficient maintenance.
- The left service door allows easy access to the engine radiator, oil cooler, air-to-air-aftercooler, primary filter with water separator (if the two are integrated) and secondary fuel filter.
- The radiator air filter features a double-element construction for superior cleaning efficiency; a warning is displayed on the monitor screen inside the cab when the filter plugs.
- An adjustable seat and joystick console are designed to meet individual preferences.
- Low-effort pilot-operated joystick controls are designed to match natural wrist and arm position for maximum comfort and minimum fatigue.
- The full-color LCD monitor is programmable in 42 languages.
- The cab shell is attached to frame with viscous rubber mounts to dampen vibrations and sound levels, enhancing operator comfort.
- Site prep and finishing work are quick and easy with a Cat® grapple, thumb, and hammer.
- Utility work is fast and flawless with a Cat bucket and compactor.
- A coupler lets you swap between attachments in seconds without leaving the cab.
- See the whole money-making attachment line for your machine at www.cat.com/attachments.
- The modified X‐frame structure provides a long service life.
- Robot-welded and stress-relieved heavy duty boom and stick are standard.
- Track shoes, links, rollers, idlers, and final drives are built with high‑tensile-strength steel.
- Greased track link between pins and bushings increases undercarriage life and reduces noise.
- Anti-skid plating covering the entire upper structure and storage box prevents slipping during maintenance.
- Countersunk bolts reduce trip hazards during service and maintenance.
- The engine radiator fan is enclosed by fine wire mesh, reducing risk of an accident.
General Duty - Leveling Edge Bucket 650 mm (25 in): 488-8415
General Duty - Leveling Edge Bucket 750 mm (29 in): 477-3375
General Duty - Leveling Edge Bucket 950 mm (37 in): 477-3376
General Duty - Leveling Edge Bucket 1150 mm (45 in): 477-3377
General Duty - Leveling Edge Bucket 1350 mm (53 in): 479-8870
General Duty - Leveling Edge Bucket 600 mm (24 in): 490-4017
General Duty - Leveling Edge Bucket 800 mm (31 in): 490-4018
General Duty - Leveling Edge Bucket 1000 mm (39 in): 490-4019
General Duty - Leveling Edge Bucket 1200 mm (47 in): 490-4020
General Duty - Leveling Edge Bucket 1400 mm (55 in): 490-4021
General Duty Bucket 1050 mm (42 in): 552-8151
General Duty Bucket 600 mm (24 in): 550-9344
General Duty Bucket 1200 mm (48 in): 552-8152
General Duty Bucket 750 mm (30 in): 550-9345
General Duty Bucket 600 mm (24 in): 550-9376
General Duty Bucket 1300 mm (51 in): 550-9349
General Duty Bucket 1200 mm (48 in): 550-9348
General Duty Bucket 900 mm (36 in): 550-9346
General Duty Bucket 1100 mm (43 in): 550-9347
General Duty Bucket 900 mm (36 in): 550-9378
General Duty Bucket 1200 mm (48 in): 550-9380
General Duty Bucket 1100 mm (43 in): 550-9379
General Duty Bucket 750 mm (30 in): 550-9377
General Duty Bucket 1400 mm (55 in): 550-9382
General Duty Bucket 1300 mm (51 in): 550-9265
General Duty Bucket 1200 mm (48 in): 550-9296
General Duty Bucket 600 mm (24 in): 550-9294
General Duty Bucket 900 mm (36 in): 550-9295
General Duty - Leveling Edge Bucket 996 mm (39 in): 455-0748
General Duty - Leveling Edge Bucket 1200 mm (47 in): 441-4768
General Duty - Leveling Edge Bucket 800 mm (31 in): 462-8167
General Duty Bucket 1300 mm (51 in): 550-9422
General Duty Bucket 600 mm (24 in): 550-9374
General Duty - Leveling Edge Bucket 650 mm (25 in): 481-1106
General Duty Bucket 750 mm (30 in): 550-9341
General Duty Bucket 1200 mm (48 in): 550-9342
General Duty Bucket 1300 mm (51 in): 550-9375
General Duty Bucket 1300 mm (51 in): 550-9343
General Duty Bucket 1400 mm (55 in): 554-3127
General Duty - Leveling Edge Bucket 1400 mm (55 in): 471-0120
Heavy Duty Bucket 1200 mm (48 in): 573-5012
Heavy Duty Bucket 1200 mm (48 in): 550-9417
Heavy Duty Bucket 1300 mm (51 in): 550-9418
Heavy Duty Bucket 1300 mm (51 in): 550-9371
Severe Duty Bucket 1050 mm (42 in): 552-8173
Severe Duty Bucket 1200 mm (48 in): 552-8174
Ditch Cleaning Bucket 1800 mm (72 in): 439-7347
Ditch Cleaning Bucket 2100 mm (82 in): 439-7348
Ditch Cleaning Bucket 1800 mm (72 in): 439-7356
Ditch Cleaning Bucket 2000 mm (78 in): 442-8270
Ditch Cleaning Bucket 2000 mm (78 in): 442-8267
Ditch Cleaning Bucket 2000 mm (78 in): 442-8266
Skeleton - Light Duty Bucket 1300 mm (51 in): 187-8849
Skeleton - Light Duty Bucket 1300 mm (51 in): 187-8850
Skeleton - Light Duty Bucket 1300 mm (51 in): 187-8851
Skeleton - General Duty Bucket 1300 mm (51 in): 445-9117
Skeleton - Heavy Duty Bucket 1200 mm (47 in): 445-9116
Grading Bucket 1600 mm (63 in): 512-8401
Grading Bucket 1700 mm (66 in): 512-8413
Grading Bucket 1700 mm (66 in): 512-8414
Grading Bucket 1800 mm (70 in): 512-8400
Profile Bucket 300 mm (12 in): 287-5360
Profile Bucket 400 mm (16 in): 287-5361
Profile Bucket 500 mm (20 in): 287-5362
Trenching Bucket 660 mm (26 in): 512-8399
Utility Duty Bucket 650 mm (26 in): 187-7678
Utility Duty Bucket 650 mm (26 in): 221-0997
Utility Duty Bucket 750 mm (30 in): 186-6731
Utility Duty Bucket 1000 mm (39 in): 186-6726
Utility Duty Bucket 1100 mm (43 in): 221-9516
Utility Duty Bucket 1200 mm (48 in): 226-2144
Utility Duty Bucket 1200 mm (48 in): 226-2145
Ditch Cleaning Tilt Bucket 2000 mm (79 in): 510-6690
Ditch Cleaning Tilt Bucket 1800 mm (72 in): 510-6691
Ditch Cleaning Tilt Bucket 2000 mm (79 in): 510-6692
Ditch Cleaning Tilt Bucket 1800 mm (72 in): 510-6693
Ditch Cleaning Tilt Bucket 2000 mm (79 in): 510-6694
G318 Demolition & Sorting Grapple: 587-8965
G317 GC Demolition & Sorting Grapple: 587-8721
G318 WH Demolition & Sorting Grapple: 587-8970
G318 WH Demolition & Sorting Grapple: 587-8975
GSH420 4-Tine, 500-Liter Orange Peel Grapple
GSH420 4-Tine, 600-Liter Orange Peel Grapple
GSH420 4-Tine, 750-Liter Orange Peel Grapple
GSH520 5-Tine, 500-Liter Orange Peel Grapple
GSH520 5-Tine, 600-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 400-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 500-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 600-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 750-Liter Orange Peel Grapple
GSV520 5-Tine, 400-Liter Orange Peel Grapple
GSV520 5-Tine, 500-Liter Orange Peel Grapple
GSV520 5-Tine, 600-Liter Orange Peel Grapple
H115 S
H120 S
H130 S
MP318 Demolition Jaw
MP318 Universal Jaw
MP318 Pulverizer Jaw
MP318 Shear Jaw
S3015 Rotating Scrap & Demolition Shear
Cat® Detect with Smart Camera
Cat® Detect with Surround Cameras
G318 Demolition & Sorting Grapple: 595-1393
G317 GC Demolition & Sorting Grapple: 587-8720
G318 Demolition & Sorting Grapple: 587-8966
MP318 Concrete Cutter Jaw
