Specification
Value
Operating Weight - With Cab
25474 lb
Weight - Drum with ROPS/FOPS
13713 lb
Weight - Drum with Cab
14010 lb
Weight - Drum with Sun Canopy
13592 lb
Specification
Value
Compaction Width
84 in
Static Linear Load - With Cab
166.8 lb/in
Static Linear Load - With ROPS/FOPS
163.3 lb/in
Ground Clearance
17.4 in
Turning Radius - Inside Drum Edge
12.07 ft
Travel Speed - Maximum
7 mile/h
Specification
Value
Gross Power
156 HP
Engine Model
Cat C7.1
Stroke
5.31 in
Bore
4.1 in
Specification
Value
Overall Length
19.25 ft
Overall Width - With Blade Option
8.25 ft
Optional Blade Height
27.1 in
Wheel Base
9.5 ft
Overall Width
7.53 ft
Drum Width
84 in
Overall Length - With Blade Option
21 ft
Drum Diameter
60.4 in
Height - With ROPS/FOPS or Cab
10.25 ft
Specification
Value
Nominal Amplitude - Low
0.039 in
Nominal Amplitude - High
0.083 in
Centrifugal Force - Minimum
31670 lb
Variable Frequency Option Range
23.3 - 30.5 Hz (1400-1830 vpm)
Centrifugal Force - Maximum
67600 lb
Vibratory Frequency - Standard
30.5 Hz (1830 vpm)
Specification
Value
Tires
23.1 x 26
Specification
Value
Fuel Tank Capacity
64 gal (US)
