Specification
Value
Operating Weight - With Cab
35264 lb
Weight - Drum with Cab
23435 lb
Operating Weight - With ROPS/FOPS Canopy
15735 kg
Weight - Drum with ROPS/FOPS Canopy
15735 kg
Operating Weight - With Steel Sun Canopy
34315 lb
Weight at Drum with Steel Sun Canopy
10440 kg
Weight at Drum with Open Platform
15470 kg
Operating Weight - With Open Platform
15470 kg
Specification
Value
Compaction Width
84 in
Ground Clearance
17.2 in
Static Linear Load - With Cab
278.7 lb/in
Travel Speed - Maximum
7 mile/h
Turning Radius - Inside Drum Edge
12.07 ft
Specification
Value
Engine Model
Cat C7.1
Gross Power
173.7 HP
Net Power - ISO 9249
145.5 HP
Net Power - SAE J1349
143.8 HP
Bore
4.1 in
Stroke
5.3 in
Specification
Value
Drum Diameter
60.4 in
Drum Width
84 in
Height - With ROPS/FOPS or Cab
10.25 ft
Optional Blade Height
27.1 in
Overall Length
19.9 ft
Overall Length - With Blade Option
21.5 ft
Overall Width
7.64 ft
Overall Width - With Blade Option
8.25 ft
Wheel Base
9.5 ft
Specification
Value
Vibratory Frequency - Standard
1680 Hz
Vibratory Frequency - Standard
28
Vibratory Frequency - Ecomode
25.5
Vibratory Frequency - Ecomode
1527
Variable Frequency Option Range
23.3 - 28 Hz (1400-1680 vpm)
Nominal Amplitude - High
0.083 in
Centrifugal Force - Maximum
74600 lb
Nominal Amplitude - Low
0.039 in
Centrifugal Force - Minimum
37300 lb
Specification
Value
Tires
23.1 x 26
Specification
Value
Fuel Tank Capacity
88 gal (US)
