PC404
Cat® Cold Planers are designed for small paving jobs in residential and commercial applications and are primarily used to economically restore asphalt and concrete surfaces. They are ideal for milling imperfections prior to resurfacing, removing deteriorated pavement, removing traffic lane stripes and jobs where the use of dedicated planers is limited. The Cat Cold Planers are designed for use on Cat Skid Steer Loaders, Compact Track Loaders, Compact Wheel Loaders and Backhoe Loaders.
Working Width
17.7 in
Maximum Cutting Depth
4.9 in
Required Hydraulics
Standard Flow
Specification
Value
Working Width
17.7 in
Maximum Cutting Depth
4.9 in
Required Hydraulics
Standard Flow
Overall Width
32.6 in
Overall Length
37.4 in
Overall Height
40.6 in
Weight
1499.1 lb
Optimal Hydraulic Flow
80-160 L/min (21-42 gal/min)
Optimal Hydraulic Pressure
160-240 bar (2320-3480 psi)
Maximum Drum Width
17.7 in
Standard Bit Type
Asphalt/Concrete
Designed for small paving jobs in residential and commercial applications, and are primarily used to economically restore asphalt and concrete surfaces. Ideal for milling imperfections prior to resurfacing, removing deteriorated pavement, removing traffic lane stripes and jobs where the use of dedicated planers is limited.
Self-leveling design automatically levels itself when placed on the ground for consistent depth control without operator adjustments and excellent spoil retention.
Manual depth control allows the operator to plane up to 5 inches.
130 degrees of rotation offers smooth, unrestricted performance.
Direct drive system features a variable speed, uni-directional, gerotor style hydraulic motor for optimum speed and torque.
