600 mm (24 in)
Nordic Digging Buckets for Cat® Mini Excavators are ideal for utility, trenching, general excavation, and backfilling in all soil types. Durable side wear plates for wear resistance in heavy duty applications. Features such as longer bucket floor length, shorter tip radius, and flat torque tube construction make them an optimal match when combined with an S Type Coupler or Tilt Rotate System.
Width
23.6 in
Capacity
5.7 ft³
Weight
235.9 lb
Specification
Value
Width
23.6 in
Capacity
5.7 ft³
Weight
235.9 lb
Base Edge Thickness
0.6 in
Tip Radius
30.9 in
Interface Type
S-40 Coupler
Designed to create maximum performance in combination with an S Type quick coupler and/or tiltrotator.
With high breakout forces combined with tiltrotator usage, the bucket still produces acceptable bucket volumes.
For low build bracket solution, close to zero offset and high bending resistance even during high stress work.
Specially designed side wear plates provide for optimal wear resistance in heavy duty applications.
For high resistance against wear even during the most demanding work environments.
