2337 mm (92 in), Smart
Cat® Dozer Blades are designed for rough and finish grading in dirt and gravel, and light dozing. With their 6-way capabilities, dozer blades are better suited for finish grade work in construction and landscaping applications.
Blade Width
92 in
Width - Fully Angled
80.7 in
Maximum Blade Angle - Right/Left of Center
30 degrees
Specification
Value
Blade Width
92 in
Width - Fully Angled
80.7 in
Maximum Blade Angle - Right/Left of Center
30 degrees
Tilt Angle Range +/-
10 degrees
Blade Height
24.4 in
Overall Height
30.9 in
Length
40.5 in
Weight
1164 lb
Cutting Edge Thickness
0.6 in
Required Hydraulics
High Flow XPS
Optimal Hydraulic Flow
42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure
145-235 bar (2100-3400 psi)
Interface Type
Skid Steer Coupler
Designed for rough and finish grading in dirt and gravel as well as for light dozing.
Attachment recognition makes the Smart Dozer Blade, Smart. Cat® Compact Track Loaders equipped with Smart technology recognizes the Smart Dozer attached to the machine, thus unlocking additional dedicated machine display screens allowing the operator to interface with the machine and how the attachment is controlled. As a Smart attachment, the existing joysticks on the machine equipped with Smart technology allow for mode select and pattern change to perform functions on the attachment.
Track-type tractor variable power angle tilt (VPAT) design with simultaneous tilt and angling capability delivers superior control and maneuverability.
Three-piece, replaceable, bolt-on, hardened cutting edge delivers long life and high performance.
An integrated spill guard prevents material from spilling over the top of the blade in full blade scenarios.
Modeled after track-type tractor blades, this allows flush cutting against a vertical surface when the blade is fully tilted.
To accept external reference masts for use by GPS, Laser, or other leveling systems.
Allows for adjustment of trunnion due to interface wear during normal usage.
Stores the OMM (Operation and Maintenance Manual) in a protective case on the attachment, where it can be conveniently accessed.
