1524 mm (60 in), Fusion™ Coupler
The Cat® Semi Millyard Forks for Small Wheel Loaders are designed to efficiently load and unload from trucks, capably sort pole and decking materials, effectively feed sawmills as well as handle other long or bulky material.
Width
84 in
Tine Spacing - Maximum Width
82.1 in
Tine Spacing - Minimum Width
60.9 in
Specification
Value
Width
84 in
Tine Spacing - Maximum Width
82.1 in
Tine Spacing - Minimum Width
60.9 in
Tine Length
60 in
Tine Width
6 in
Maximum Clamp Opening
98.8 in
Minimum Clamp Opening
6 in
Weight
4627.5 lb
Interface Type
Fusion™ Coupler
Efficiently unload and load from trucks, capably sort pole and decking inventory in the yard, effectively feed sawmills and handle other long or bulky material.
90 degree flat back tines allows for carrying palletized lumber and other items as well as loose logs.
Adjustable tines can be configured to 9 different spacing setups, allowing for complete flexibility to your particular applications.
Narrow top clamp is designed to close between the tines, which would allow the operator to clamp tightly on a single log.
Floating/non-floating tines are adjustable to 3 different spacing configurations, and can be locked, or setup to float.
Tool mounted and sealed from the elements, holder includes all operation manuals and maintenance guides required for proper operation of the work tool.
