1219 mm (48 in)
Cat® Heavy Duty Fork Tines for use with Cat heavy duty fork carriages are designed to meet a wide variety of material handling needs above those, that a standard pallet fork can handle. Fork tines come in different sizes to accommodate moving bulky or palletized materials on construction and industrial sites.
Overall Length
50.9 in
Tine Length
48 in
Width
4.8 in
DOWNLOAD TECHNICAL SPECIFICATIONS
Specification
Value
Overall Length
50.9 in
Tine Length
48 in
Width
4.8 in
Height
21.6 in
Tine Thickness
1.8 in
Load Capacity
6199.4 lb
Weight
291 lb
Used for a variety of material handling needs, such as moving bulky or palletized materials on construction and industrial sites, handling bagged fertilizer and seed at landscaping and nursery sites, and similar jobs.
Heavy Duty Forks are rated Class II to handle lifting requirements of Skid Steer, Multi Terrain and Compact Track Loader machines.
Heavy Duty Fork length options - 1067 mm (42 in), 1219 mm (48 in) and 1524 mm (60 in).
