COMPARE MODELS
Our product comparison allows for the review of up to 3 related models technical specifications at the same
time.
Three Axle Articulated Trucks
735
ADD MODEL
ADD MODEL
Engine Model
Cat® C13
Na
Na
Bore
5.1 in
Na
Na
Stroke
6.2 in
Na
Na
Displacement
736 in³
Na
Na
Net Power - ISO 14396
404 HP
Na
Na
Peak Engine Torque Gross (SAE J1995)
1617 ft·lbf
Na
Na
Net Power - SAE J1349
400 HP
Na
Na
No Engine De-rating Below
12500 ft
Na
Na
Gross Power - SAE J1995
410 HP
Na
Na
Peak Engine Torque Speed
1200 r/min
Na
Na
Note (3)
Net power when the fan is at maximum speed is 254 kW (341 hp) per the SAE reference conditions.
Na
Na
Note (1)
The operator sound exposure Leq (equivalent sound pressure level) measured according to the work cycle procedures specified in ANSI/SAE J1166 OCT98 is 72 dB(A), for the cab offered by Caterpillar, when properly installed and maintained and tested with the doors and windows closed.
Na
Na
Emissions
The 735 meets either Tier 2/Stage II or Tier 3/Stage IIIA equivalent emission standards.
Na
Na
Engine Model - Either U.S. EPA Tier 2/EU Stage II or U.S. EPA Tier 3/EU Stage IIIA equivalent
Cat C13
Na
Na
Peak Engine Torque Net (SAE J1349/ISO 9249)
1589 ft·lbf
Na
Na
Rated Payload
35.3 ton (US)
Na
Na
Heaped (SAE 2:1)
26.2 yd³
Na
Na
Struck
20.3 yd³
Na
Na
Tailgate Heaped SAE 2:1
27.9 yd³
Na
Na
Tailgate Struck
21.3 yd³
Na
Na
Forward - 1
5 mile/h
Na
Na
Forward - 2
9 mile/h
Na
Na
Forward - 3
14 mile/h
Na
Na
Forward - 4
22 mile/h
Na
Na
Forward - 5
30 mile/h
Na
Na
Forward - 6
35 mile/h
Na
Na
Reverse - 1
6 mile/h
Na
Na
Interior Cab
72 dB(A)
Na
Na
Note (2)
The net power advertised is the power available at the flywheel when the engine is equipped with alternator, air cleaner, muffler and fan at minimum speed.
Na
Na
Rear Axle - Loaded
41447 lb
Na
Na
Rear Axle - Rated Load
30754 lb
Na
Na
Rear Axle - Empty
10692 lb
Na
Na
Front Axle - Rated Load
9039 lb
Na
Na
Center Axle - Empty
11177 lb
Na
Na
Total - Empty
54851 lb
Na
Na
Front Axle - Loaded
42020 lb
Na
Na
Center Axle - Loaded
41932 lb
Na
Na
Total - Loaded
125399 lb
Na
Na
Center Axle - Rated Load
30754 lb
Na
Na
Total - Rated Load
70548 lb
Na
Na
Front Axle - Empty
32981 lb
Na
Na
Fuel Tank
108.8 gal (US)
Na
Na
Cooling System
21.9 gal (US)
Na
Na
Hydraulic System
29.1 gal (US)
Na
Na
Engine Crankcase
10 gal (US)
Na
Na
Transmission
12.3 gal (US)
Na
Na
Final Drives/Differential
33 gal (US)
Na
Na
Output Transfer Gear Box
5.5 gal (US)
Na
Na
Raise Time
12 s
Na
Na
Lower Time
11 s
Na
Na
Lock to Lock
4.75 seconds @ 60 rpm
Na
Na
Brakes
ISO 3450 – 2011
Na
Na
Cab - FOPS
ISO 3449 Level II – 2005
Na
Na
Cab - ROPS
ISO 3471 – 2008
Na
Na
Steering
ISO 5010 – 2007
Na
Na
Type
High strength Brinell HB450 wear resistant steel
Na
Na
Turning Dimensions - SAE Turning Radius
294 in
Na
Na
Turning Dimensions - Aisle Width
212 in
Na
Na
Turning Dimensions - Clearance Radius
318 in
Na
Na
Turning Dimensions - Steer Angle - Left/Right
45°
Na
Na
Turning Dimensions - Inside Radius
149 in
Na
Na
Note
An optimum system match gives you a major productivity advantage. The 735 is an excellent match for the Cat 349F and 336F Hydraulic Excavators; and Cat 972M, 966M, 962M and 950M Wheel Loaders. Having matched loading and hauling tools results in increased production and lower system costs per unit of volume moved.
Na
Na
Front Plate
0.28 in
Na
Na
Base Plate
0.51 in
Na
Na
Side Plates
0.43 in
Na
Na
Wheel Loaders: 972M/972M XE - Passes
3–4
Na
Na
Hydraulic Excavators: 349F/349F XE - Passes
4–5
Na
Na
Wheel Loader: 950M - Passes
5
Na
Na
Wheel Loaders: 966M/966M XE - Passes
4
Na
Na
Wheel Loader: 962M - Passes
4–5
Na
Na
Hydraulic Excavators: 336F/336F XE - Passes
5–6
Na
Na
